He used a MIDI cable that does not bring out the negative pin on the controller connector, so I don’t see how that common connection is made. However this must mean there is a common negative connection between the Arduino and the camera mount. I think it happens to work as it is because one wires ends up getting pulled to negative (-) like the original controller use to do. To move the other direction it reverses which wire gets + and which gets. Review of pan&tilt motorized tripod head known as Maxwell Electronic Power Panner, Bescor MP-101 Motorized Pan Head, or Hague Pan & Tilt Power Head. ★Like the video? The Bescor MP 101 is now one of my key pieces of equipment in my video and audio arsenal.
To move one direction, it attaches one wire of the coil to positive (+) and the other to negative (-).
Bescor mp 101 cable hack driver#
A motor shield is a H-bridge driver meaning it expects to be directly connected to motor coils. To mimic that, directly attaching each direction wire to an IO pin is suitable. Here are my observations: It seems the original controller simply tied each direction button to GND (through a resistor). Matt, Someone pointed me to your site wondering why you used a motor shield, and I’m a bit unsure why you chose to as well. If you have any questions, please or leave a comment.
Bescor mp 101 cable hack code#
Each line of code below will be labeled and hopefully help you understand the process. (Update: Here’s a to installing the Arduino Software.) Here’s a to the library we’ll be using to get the Nunchuck working. If anyone’s interested in a in depth tutorial about using the Arduino software, please leave a comment.
Bescor mp 101 cable hack drivers#
Step 3: Connect the Nunchuck Wires to the Arduino Motor Shield The wires are connected as followed on the motor shield: Yellow – GND Black – A5 Red – A4 Brown – 3.3v Step 4: Connect the MIDI Wires to the Arduino Motor Shield The wires are connected as followed: Yellow– (-B) Blue – (+B) Purple – (-A) Red – (+A) Yellow/ Blue – Tilt, Purple/ Red – Pan Step 5: Program the Arduino In this step, the and drivers need to be installed on the computer. If you use a different extension, the wire colors might be in a different order. Yellow – Ground Black – Clock Red – Data Brown – Power These wires will connect to the Arduino pins and later I’ll show in the code the pin assignments. (Note: The wire colors from other cables might be different from the original cable.) Step 2: Strip the Nunchuck Extension Wires To connect the Wii Nunchuck controller, I used extension. It’s also possible to use the original cable. Step 1: Strip the MIDI Wires I’ll be using a five pin MIDI cable like. I searched for a better remote, but couldn’t find one at a reasonable price, so after trying a few experiments, I found using the Nunchuck, the, and the together, I could make a great controller.
Also, the speed slider is difficult to use while panning. First off, the only allows movement on one axis at a time. Here’s the The Bescor MP-101 pan and tilt is a great cost effective solution for video and photo setups, but it has several limitations. I’ll try to get a working prototype up this week. Update: Thanks to, there is a better way to connect the Bescor to the Arduino instead of using the Motor Shield.
